B0092 Code Explained: Right Side Airbag Deployment Loop Resistance High (Subfault)

OBD-II scanner displaying B0092 beside a passenger seat with the side airbag highlighted and a corroded SRS connector beneath the seat illustrating a high-resistance deployment circuit fault.

If your scan tool displays B0092, your vehicle has detected higher-than-normal electrical resistance in the Right Side Airbag deployment circuit. This Body (B) diagnostic trouble code (DTC) indicates a fault within the Supplemental Restraint System (SRS) that could prevent the passenger-side side-impact airbag (or right curtain airbag on some vehicles) from deploying properly during a side-impact collision.

The Airbag Control Module (ACM) continuously monitors every airbag deployment circuit by measuring electrical resistance. If it detects resistance above the manufacturer’s specified range in the Right Side Airbag deployment loop, it stores B0092 and illuminates the Airbag Warning Light.

High-resistance faults are commonly caused by corroded connectors, loose terminals, partially broken wiring, moisture intrusion, or an internally faulty airbag module. Since this code affects a critical safety system, it should be diagnosed and repaired promptly.

If you’re researching additional SRS or Body diagnostic trouble codes, visit our Complete OBD-II Trouble Code Guide:

https://my.prostreetonline.com/dtc-obdii

Quick Facts

ItemInformation
OBD-II CodeB0092
DescriptionRight Side Airbag Deployment Loop Resistance High (Subfault)
CategoryBody (B) Codes
SystemSupplemental Restraint System (SRS)
Severity★★★★★ Critical
Safe to Drive?Mechanically yes, safety-wise no
Common CausesCorroded connectors, damaged seat wiring, loose terminals, faulty side airbag module
Typical Repair Cost$150–1,800

What Does B0092 Mean?

The B0092 code indicates the Airbag Control Module (ACM) has detected electrical resistance above the acceptable operating range within the Right Side Airbag deployment circuit.

Depending on the manufacturer, the deployment loop may include:

Whenever the ignition is switched on, the ACM performs a self-test by measuring the resistance of every deployment circuit. If the measured resistance exceeds the manufacturer’s specification, the ACM interprets the condition as an electrical fault that could prevent proper airbag deployment during a collision.

If you’re troubleshooting related SRS codes, you may also find these guides helpful:

Symptoms of B0092

Common symptoms include:

Although the vehicle typically drives normally, the passenger-side airbag may not deploy correctly during a side-impact collision.

Common Causes

Corroded SRS Connectors

Corrosion inside SRS connectors increases electrical resistance and is among the leading causes of B0092.

Loose Electrical Terminals

Loose connector pins may create poor electrical contact, resulting in excessive resistance.

Damaged Passenger Seat Wiring

Because many passenger-side airbags are mounted within the seat, wiring may become:

Faulty Side Airbag Module

An internal electrical fault within the passenger-side side airbag inflator can increase circuit resistance.

Previous Collision or Interior Repairs

Improper repairs may introduce:

Airbag Control Module Failure

Although uncommon, an internal ACM failure may falsely report excessive circuit resistance.

How Serious Is B0092?

Extremely serious.

If the Right Side Airbag deployment circuit is disabled:

Repairs should be completed as soon as possible.

Can You Drive With B0092?

Mechanically, yes.

From a safety standpoint, no.

The vehicle will usually continue driving normally, but the passenger-side airbag may not deploy properly during a collision.

How to Diagnose B0092

1. Scan the SRS Module

Use a professional scan tool capable of reading manufacturer-specific Body (B) codes.

Most basic OBD-II scanners cannot communicate with the Airbag Control Module.

2. Inspect Passenger Seat Wiring

Inspect wiring beneath the passenger seat for:

3. Inspect SRS Connectors

Inspect connectors for:

4. Verify Circuit Resistance

Using manufacturer-approved SRS diagnostic procedures, verify deployment loop resistance.

Never apply battery voltage, use a powered test light, or directly probe an airbag inflator. Airbag systems contain pyrotechnic devices that can deploy unexpectedly if tested improperly.

5. Inspect the Passenger Side Airbag Module

If the wiring and connectors test within specification, inspect the airbag module for:

Common Repairs

RepairEstimated Cost
Repair passenger seat wiring$150–400
Replace SRS connector$100–250
Replace side airbag module$500–1,000
Replace seat wiring harness$250–600
Replace Airbag Control Module$900–1,800

Common Diagnostic Mistakes

One of the most common mistakes is replacing the passenger-side airbag module before inspecting the passenger seat wiring and SRS connectors.

Many B0092 repairs are ultimately traced to:

Always inspect the complete deployment circuit before replacing expensive SRS components.

Vehicles Commonly Affected

B0092 may appear on vehicles from many manufacturers, including:

Manufacturer-specific resistance specifications, wiring diagrams, and repair procedures vary by make and model.

How to Prevent B0092

Although not every failure can be prevented, you can reduce the likelihood of B0092 by:

Frequently Asked Questions

What causes B0092?

Common causes include corroded connectors, damaged passenger seat wiring, loose electrical terminals, faulty side airbag modules, previous collision repairs, or a defective Airbag Control Module.

Is B0092 dangerous?

Yes.

The code can disable the right-side airbag deployment circuit, reducing passenger protection during a side-impact collision.

Can moving the passenger seat cause B0092?

Yes.

Repeated passenger seat movement can stretch or damage wiring beneath the seat, increasing circuit resistance.

Can I clear B0092 myself?

Yes.

However, unless the underlying electrical problem has been repaired, the code will generally return during the next SRS self-test.

Will B0092 affect vehicle performance?

No.

The code only affects the Supplemental Restraint System and does not impact engine, transmission, steering, or braking performance.

Final Thoughts

The B0092 code indicates that the Right Side Airbag deployment circuit has higher-than-normal electrical resistance, most commonly caused by corroded connectors, loose terminals, damaged passenger seat wiring, previous collision repairs, or an internally faulty side airbag module.

Although the vehicle will usually continue driving normally, the passenger-side airbag may not deploy correctly during a side-impact collision. Prompt diagnosis using manufacturer-approved SRS procedures is essential to restore full Supplemental Restraint System protection.

For additional airbag diagnostics and Body code repair guides, browse our complete Body (B) OBD-II Code Library:

https://my.prostreetonline.com/category/how-to/dtc-obdii
