C0906 Code Explained: Causes, Symptoms & Device Current Circuit Fixes

An OBD-II scanner displaying C0906 beside an electronic chassis actuator with an open wiring circuit, blown fuse, relay, multimeter probes, and illuminated ABS and 4WD warning lights.

If your scan tool displays C0906, one of your vehicle’s electronic chassis control modules has detected a fault in the current circuit used to operate or monitor an electronic actuator. Unlike C0905 (Device Current Performance), which indicates an actuator is drawing abnormal current while operating, C0906 typically means there is a problem with the electrical circuit itself, preventing the module from properly controlling or monitoring the device.

On many GM vehicles, C0906 is commonly stored by the Electronic Brake Control Module (EBCM), Transfer Case Control Module (TCCM), Electronic Suspension Control Module (ESCM), or another chassis controller when it detects an open circuit, excessive resistance, damaged wiring, or another electrical fault affecting an actuator.

In most cases, C0906 is caused by damaged wiring, corroded connectors, blown fuses, faulty relays, poor ground connections, or an internally failed actuator—not a defective control module.

For additional chassis diagnostic guides, visit our Complete OBD-II Trouble Code Library:

https://my.prostreetonline.com/dtc-obdii

Quick Facts

ItemInformation
OBD-II CodeC0906
DescriptionDevice Current Circuit
CategoryChassis (C) Codes
SystemChassis Electronics / Actuator Circuit
Severity★★★★☆ High
Safe to Drive?Usually, but the affected chassis system may be disabled
Common CausesOpen wiring, faulty actuator, blown fuse, bad relay, poor ground
Typical Repair Cost$75–1,200

What Does C0906 Mean?

The C0906 code indicates that a chassis control module has detected a fault within the electrical current circuit controlling or monitoring an electronic actuator.

Unlike voltage-related diagnostic trouble codes, C0906 focuses on whether the module can successfully deliver and monitor electrical current through the actuator circuit.

If the control module detects problems such as:

it stores C0906.

Unlike C0905, which usually indicates an actuator is operating but drawing abnormal current, C0906 often means the actuator cannot operate correctly because the electrical circuit itself has failed.

Depending on the vehicle, affected components may include:

If the control module cannot reliably control current flow, it will usually disable the affected chassis system to prevent further damage.

Symptoms of C0906

Common symptoms include:

Additional symptoms may include:

Symptoms depend on which actuator is affected.

Common Causes

Open Circuit

Broken wiring is one of the most common causes of C0906.

Open circuits may result from:

Without electrical continuity, the actuator cannot operate.

Damaged Wiring Harness

The actuator wiring harness may become damaged from:

Harness failures frequently create intermittent faults.

Corroded Electrical Connectors

Moisture intrusion may create excessive resistance.

Inspect for:

Blown Fuse

Many chassis actuators receive power through dedicated fuses.

A blown fuse completely interrupts current flow and immediately triggers C0906.

Always determine why the fuse failed before replacing it.

Faulty Relay

High-current devices often operate through relays.

Common relay failures include:

Poor Ground Connection

Ground problems can interrupt actuator operation even when battery voltage is present.

Inspect:

Voltage-drop testing is recommended.

Failed Actuator

Internal actuator failures include:

The actuator may no longer draw current at all.

Water Intrusion

Water entering connectors or actuator housings can damage internal electrical components.

Vehicles frequently exposed to:

are more susceptible.

Faulty Control Module

Although uncommon, an internal driver circuit inside the module may fail.

Module replacement should only be considered after verifying all external wiring and components.

How Serious Is C0906?

High.

The vehicle often remains drivable, but the affected electronic chassis system may become completely inoperative.

Potential consequences include:

Ignoring the fault may eventually lead to additional electrical damage.

Can You Drive With C0906?

Usually, yes—but repairs should be completed promptly.

Depending on the affected actuator, you may lose:

Vehicle safety may be reduced during emergency maneuvers or poor weather conditions.

How to Diagnose C0906

1. Scan All Modules

Check for additional:

Additional DTCs often identify the affected actuator.

2. Command the Actuator

Using a professional scan tool:

If the actuator does not respond, continue electrical testing.

3. Check Power and Ground

Using a digital multimeter:

Poor power or ground commonly triggers C0906.

4. Inspect the Wiring Harness

Check for:

Repair damaged sections.

5. Test Fuses and Relays

Inspect:

Replace defective components only after identifying the underlying cause.

6. Test Actuator Resistance

Disconnect the actuator and measure winding resistance.

Compare readings with manufacturer specifications.

An open circuit usually indicates internal motor failure.

7. Verify Repairs

After repairs:

Common Repairs

RepairEstimated Cost
Repair damaged wiring$100–450
Replace electrical connector$75–250
Replace actuator motor$250–900
Replace fuse$25–75
Replace relay$50–175
Repair ground connection$75–200
Replace chassis control module (if required)$700–1,600

Common Diagnostic Mistakes

Technicians frequently:

Vehicles Commonly Affected

C0906 is commonly reported on:

Similar current circuit faults may also appear on Ford, Ram, Jeep, Toyota, Honda, Nissan, Hyundai, Kia, Subaru, Volkswagen, BMW, Mercedes-Benz, Audi, and many other vehicles equipped with electronically controlled chassis systems.

How to Prevent C0906

Reduce the likelihood of C0906 by:

Frequently Asked Questions

What causes C0906?

The most common causes include damaged wiring, open circuits, faulty actuators, blown fuses, defective relays, poor ground connections, connector corrosion, or water intrusion.

Is C0906 serious?

Yes.

Although many vehicles remain drivable, important systems such as ABS, four-wheel drive, stability control, or adaptive suspension may no longer operate correctly.

Can a blown fuse cause C0906?

Absolutely.

A blown fuse interrupts current flow to the actuator and is one of the most common causes of this code.

Can damaged wiring trigger C0906?

Yes.

Broken wires, high resistance, loose connectors, and corrosion frequently prevent proper current flow through the actuator circuit.

Will replacing the actuator fix C0906?

Only if the actuator has failed internally.

The wiring, relay, fuse, power supply, and ground circuits should always be tested before replacing expensive components.

Final Thoughts

The C0906 code indicates that a chassis control module has detected a fault within the electrical current circuit controlling an electronic actuator. Unlike current performance faults, C0906 usually points to a wiring, connector, fuse, relay, or continuity problem that prevents the actuator from operating correctly. In most cases, the issue can be traced to damaged wiring, poor electrical connections, or an internally failed actuator rather than the control module itself.

A proper diagnosis should begin by verifying power and ground at the actuator, checking fuses and relays, inspecting the wiring harness, and performing continuity and voltage-drop testing. Correcting the underlying electrical fault will usually restore normal operation and clear the C0906 code.
