If your scan tool displays C0275, your vehicle’s Electronic Brake Control Module (EBCM) has detected a short to voltage in the ABS delivery solenoid circuit within the Hydraulic Control Unit (HCU).
The delivery solenoid—also called the isolation solenoid—is responsible for controlling hydraulic brake pressure during Anti-lock Braking System (ABS) operation. During hard braking, the EBCM energizes this solenoid to isolate brake pressure and prevent wheel lockup. If the delivery solenoid circuit unexpectedly receives battery voltage when it shouldn’t, the EBCM can no longer accurately control the solenoid. It stores C0275 and typically disables the ABS, Traction Control (TCS), and Electronic Stability Control (ESC/StabiliTrak) systems until the problem is repaired.
Unlike C0274, which indicates a short to ground, C0275 means the circuit is receiving excessive voltage due to an unintended connection to a power source.
For additional chassis diagnostics and repair guides, visit our Complete OBD-II Trouble Code Guide:
https://my.prostreetonline.com/dtc-obdii
Quick Facts
| Item | Information |
|---|---|
| OBD-II Code | C0275 |
| Description | ABS Delivery Solenoid Circuit Short to Voltage |
| Category | Chassis (C) Codes |
| System | Anti-lock Braking System (ABS) |
| Severity | ★★★★☆ High |
| Safe to Drive? | Yes, but ABS and stability systems will likely be disabled |
| Common Causes | Shorted wiring, damaged harness, internally shorted Hydraulic Control Unit, faulty EBCM, water intrusion |
| Typical Repair Cost | $100–2,000 |
What Does C0275 Mean?
The C0275 code indicates the Electronic Brake Control Module has detected an unexpected voltage source in the ABS delivery (isolation) solenoid circuit.
Under normal conditions, the EBCM supplies voltage to the delivery solenoid only when necessary during an ABS event. The module also monitors the circuit to verify that voltage appears and disappears exactly as commanded.
If battery voltage is present when the circuit should be inactive, the EBCM recognizes a short-to-voltage condition and disables the ABS system.
The EBCM continuously monitors:
- Circuit voltage
- Current flow
- Solenoid resistance
- Driver output
- Commanded versus actual operation
A short-to-voltage fault prevents the EBCM from safely controlling hydraulic brake pressure, so ABS operation is suspended until repairs are completed.
Symptoms of C0275
Common symptoms include:
- ABS warning light illuminated
- Traction Control warning light
- Electronic Stability Control warning
- Service Brake System message
- Service StabiliTrak message (GM vehicles)
- ABS disabled
- Traction Control unavailable
- Stability control disabled
- Stored C0275 diagnostic code
In most cases, normal hydraulic braking remains functional.
Common Causes
Wiring Shorted to Battery Voltage
The most common cause is wiring that has contacted a constant 12-volt power source.
This may occur because of:
- Damaged wire insulation
- Pinched harnesses
- Improper repairs
- Harness routing problems
Melted Wiring Harness
Heat from the engine or exhaust system can melt wire insulation, allowing the delivery solenoid circuit to contact adjacent power wires.
Water Intrusion
Moisture inside connectors can create conductive bridges between battery voltage and the delivery solenoid circuit.
Damaged Electrical Connectors
Inspect connectors for:
- Corrosion
- Bent terminals
- Loose pins
- Broken locks
- Moisture contamination
Hydraulic Control Unit Failure
An internal electrical short inside the Hydraulic Control Unit may apply voltage to the delivery solenoid circuit.
Since the delivery solenoid is integrated into the HCU on many vehicles, replacement of the hydraulic assembly may be necessary.
Faulty Electronic Brake Control Module
Although uncommon, an internal EBCM driver failure can incorrectly energize the delivery solenoid or falsely detect a short-to-voltage condition.
Improper Aftermarket Wiring
Poorly installed accessories—including alarms, remote starters, lighting systems, and trailer brake controllers—can accidentally introduce voltage into the ABS wiring harness.
How Serious Is C0275?
High.
When C0275 is active, the Electronic Brake Control Module typically disables:
- Anti-lock Braking System
- Traction Control
- Electronic Stability Control
- Brake Assist
While the vehicle retains normal hydraulic braking, it loses several important electronic safety features that improve control during emergency maneuvers.
Can You Drive With C0275?
Yes—but carefully.
The vehicle can usually be driven safely under normal conditions.
However:
- Wheels may lock during panic stops.
- Steering control during hard braking is reduced.
- Traction control cannot reduce wheel spin.
- Stability control cannot help prevent skids.
Prompt diagnosis and repair are recommended.
How to Diagnose C0275
1. Scan the ABS Module
Use a professional scan tool capable of reading manufacturer-specific ABS codes.
Look for related codes such as:
- C0271
- C0272
- C0273
- C0274
- C0276
- C0265
- U-series communication codes
2. Verify Battery Voltage
Confirm:
- Battery voltage
- Charging voltage
- Ground integrity
Abnormally high charging voltage may contribute to electrical faults.
3. Inspect the Wiring Harness
Carefully inspect the delivery solenoid wiring for:
- Melted insulation
- Pinched wiring
- Contact with power wires
- Previous repair splices
- Rodent damage
4. Test for Short to Voltage
Disconnect the EBCM connector and use a digital multimeter to measure voltage on the delivery solenoid control circuit.
Battery voltage present with the circuit disconnected typically confirms a short-to-voltage condition.
5. Measure Solenoid Resistance
Compare measured resistance to manufacturer specifications.
Values outside specification may indicate an internally damaged Hydraulic Control Unit.
6. Perform Active Solenoid Testing
Many professional scan tools allow technicians to command the delivery solenoid.
Verify:
- Solenoid activation
- Circuit voltage
- Current draw
- Driver feedback
Unexpected voltage during inactive commands often confirms the fault.
7. Inspect the Hydraulic Control Unit
If wiring checks good but voltage remains present, inspect or replace the Hydraulic Control Unit.
Some vehicles allow replacement of the Electronic Brake Control Module separately, while others require replacement of the complete ABS hydraulic assembly.
Common Repairs
| Repair | Estimated Cost |
|---|---|
| Repair damaged wiring | $100–350 |
| Replace damaged connector | $75–200 |
| Correct aftermarket wiring | $100–300 |
| Replace Hydraulic Control Unit | $700–1,800 |
| Replace Electronic Brake Control Module | $800–2,000 |
| Module programming | $100–250 |
Common Diagnostic Mistakes
Technicians frequently:
- Replace wheel speed sensors unnecessarily.
- Replace the Hydraulic Control Unit before checking the wiring harness.
- Ignore aftermarket wiring modifications.
- Fail to test for battery voltage on the control circuit.
- Overlook connector corrosion.
- Skip active solenoid testing.
Vehicles Commonly Affected
C0275 is commonly reported on:
- Chevrolet Silverado
- GMC Sierra
- Chevrolet Tahoe
- GMC Yukon
- Chevrolet Avalanche
- Chevrolet Suburban
- Cadillac Escalade
- Chevrolet Express
- GMC Savana
- Chevrolet TrailBlazer
- GMC Envoy
Similar delivery solenoid short-to-voltage faults may also occur on vehicles equipped with Bosch ABS hydraulic systems from other manufacturers.
How to Prevent C0275
Reduce the likelihood of C0275 by:
- Inspecting ABS wiring during brake service.
- Securing wiring away from exhaust components.
- Repairing damaged insulation promptly.
- Avoiding poor-quality electrical modifications.
- Keeping connectors clean and dry.
- Addressing ABS warning lights immediately.
Frequently Asked Questions
What causes C0275?
The most common causes include wiring shorted to battery voltage, damaged harnesses, internally shorted Hydraulic Control Units, connector damage, aftermarket wiring problems, or an Electronic Brake Control Module fault.
Is C0275 serious?
Yes.
Although normal braking remains available, losing ABS, traction control, and stability control reduces safety during emergency braking and slippery road conditions.
Can aftermarket accessories cause C0275?
Yes.
Improperly installed electrical accessories are a common source of short-to-voltage conditions that affect ABS wiring.
Does C0275 mean the Hydraulic Control Unit has failed?
Not necessarily.
The wiring harness should always be tested first before replacing expensive ABS components.
Does C0275 affect engine performance?
No.
The code only affects the braking and chassis control systems.
Final Thoughts
The C0275 code indicates a short-to-voltage condition in the ABS delivery solenoid circuit, preventing the Electronic Brake Control Module from accurately controlling hydraulic brake pressure during anti-lock braking events. While conventional braking usually remains functional, the loss of ABS, traction control, and stability control can significantly reduce vehicle control during emergency situations.
Most repairs involve tracing unwanted battery voltage in the wiring harness, repairing damaged connectors, testing the delivery solenoid, and determining whether the Hydraulic Control Unit or Electronic Brake Control Module has failed. A careful electrical diagnosis can prevent unnecessary replacement of expensive ABS components and restore full braking system functionality.
